LEVEL 1 (Page 1 & 2)
Total Area:
Living Area: 431 sq ft
Bedroom (Non-living area): 157 sq ft
Utility (Non-living area): 63 sq ft
Room-Level Measurements (from diagram on Page 1)
Recreation Room:
12'7" (width, horizontal)
13'5" (depth, vertical)
Bedroom (1):
13'11" (width)
11'3" (depth)
Utility (2):
11'3" (width)
10'9" (depth)
Full Bath:
6'10" (width)
5'5" (depth)
Hall: unlabeled, but stair width is labeled:
Stairs: 2'5" wide (two places shown)
Overall Exterior Span:
20'9" (top horizontal width)
31'2" (right vertical height)
LEVEL 2 (Page 3)
Total Living Area: 681 sq ft
Room-Level Measurements
From the floor plan on Page 3:
Kitchen:
21'10" (full horizontal span including kitchen + dining + living)
Dining Area:
Integrated within the 21'10" span
No independent dimension
Living Room:
21'10" (width)
31'2" (overall height for entire floor includes foyer & half bath)
Entry: unlabeled dimension
Half Bath:
5'9" (depth)
2'5" (width)
Additional Room:
No labeled dimensions
Foyer:
2'5" (stair width)
Entire foyer zone sits in the 31'2" total height
LEVEL 3 (Page 4)
Total Living Area: 681 sq ft
Room-Level Measurements
Kitchen:
Same structural span as Level 2: 21'10"
Dining Area:
No independent dimension
Sitting Room:
21'10" span (shared width)
Height matches full floor: 31'2"
Half Bath:
5'9" (depth)
2'5" (width)
Laundry:
4'4" (width)
5'3" (approx. depth from diagram)
Room (additional):
No labeled dimensions
Full depth uses the 31'2" floor height
LEVEL 4 (Page 5)
Total Living Area: 681 sq ft
Room-Level Measurements
Primary Bedroom:
21'10" (full width)
~15' range (visually between 14'–16')
Bedroom (middle):
21'10" (width shared with floor)
Approx. 15' depth
Bedroom (front):
21'10" width
Depth slightly smaller (~11'–13')
Full Bath:
5'4" (depth)
~6'8" width (visually sourced from diagram)
Laundry:
~5'4" × 4'4"
Hall:
Stairs: 2'5" width
Total floor height: 31'2"
SUMMARY OF AREAS (From CubiCasa Text + Diagrams)
Level 1:
431 sq ft living
157 sq ft bedroom (non-GLA)
63 sq ft utility (non-GLA)
Level 2:
681 sq ft living
Level 3:
681 sq ft living
Level 4:
681 sq ft living
Total GLA: 2,474 sq ft
